Main Features
10X[1] Faster
Compared to mainstream FDM 3D printers, the printing speed has
increased by 10 times. Larger model creation, time-saving, and
energy-efficient.
[1] Compared to products with a average printing speed of 50mm/s, data from Anycubic Lab, results are for reference only.
High-Performance Processor, Strong Computing Power
Equipped with a high-performance Cortex-A7 1.2GHz processor, it
provides strong computing power for faster calculations, execution of
commands, motor control, resulting in 10 times faster printing.
Optimized Configuration, Brand New Structure
By using direct extruder and a dual-motor dual-Z-axis motion
structure that have been perfectly optimized for the extrusion and
cooling systems, it efficiently and accurately delivers materials,
allowing for quick melting and cooling. This leads to smooth operation
and fewer visible layer lines.
Vibration Compensation and Flow Control
The one-click “Vibration Compensation” detects the resonance
frequency of the X/Y axes and adjusts the motion control intelligently
to effectively eliminate resonance vertical lines and bracket lines,
ensuring printing accuracy and stability. With “Flow Control”,
intelligent compensation for retraction and refilling ensures evenly and
fully printed layers, enhancing print quality and detail
representation.
41 Liter Large Volume Accelerates Large Builds
320*320*400mm large printing size, can print models of approximately
41 liters in volume at one time. Full-sized printing of the same model,
compared to similar products on the market with a printing speed of
50mm/s, printing time is shortened by 31 h 35 mins, efficient creation,
energy-saving, and environmental-friendly.
Supports Anycubic APP[2] Control Made “Smart”
With the new version of Anycubic APP remote networking firmware
upgrading, and real-time viewing of printer status are achievable.
Future updates will also support online slicinc and printing, video
monitoring[3] and time-lapse photography remote control and management, and an open model library function module, kick-starting a “smart”.
[2] The Anycubic APP is expected to be launched in Q4 of 2023.
[3] Users need to prepare their own cameras to enable video monitoring functionality.
LeviQ 2.0 Automatic Leveling Smart Z-Offset[4]
By designing a unique module, after automatic leveling, it can
intelligently compensate for Z-axis offset, while also supporting custom
Z-axis compensation values, meeting the needs of different users and
usage environments.One-click quick start for creative ideas, ensuring
successful printing.
[4] Z-Offset deviation might
occur due to the uncontrollable shipping environment. Please adjust the
Z-Offset in accordance with the circumstances.
Several Detail Designs, Easy Creation
Models Display
Tech Specs
Machine Weight: 13kg
Machine Dimensions:24.8×23.8×22.2in./ 630x605x564mm(HWD)
Printing Volume: 10.8gal./40.9L
Printing Dimensions: 15.7×12.6×12.6in./ 400x320x320mm(HWD)
Nozzle : ≤500℉/260°C ø 0.4mm (replaceable)
Hotbed Temperature: ≤190℉/90°C
Printing Speed: 500mm/s(Max.) 300mm/s(Typ.)
Z-axis: Double Motor Doble Z-axis
X/Y axis: Double Metal Spindle
X/Y axis: Belt Tensioner: Included
Filament Detection: Default
Machine Leveling: New Anycubic LeviQ 2.0 Automatic Leveling System (49-point)
Printing Platform: PEl Magnetic Spring Steel 12.6×12.6in./320x320mm
Extruder: Direct Extruder + Double Gears
Cooling Fan RPM: 7000rpm/min
Control Panel: 4.3″ LCD Touch-Control Screen
Motherboard: 32-bit Silent Motherboard
Power Supply: 400W
Printing Material: PLA/ABS/PETG/TPU
Data Input: USB Port x 3
