Anycubic Standard resin 1KG
anycubic Standard UV resin 1L is one of Anycubic’s translucent photo-sensitive 3D printing materials. It’s tough and durable, and it sticks to the build platform well, enhancing your print success rate. It has a nice blend of hardness and toughness, making it less difficult to remove from the build platform. The finished parts have a transparent appearance and a high level of detail. In both damp and corrosive settings, they have good stability.
anycubic UV resin 1L is designed for efficient DLP 3D printing with minimal energy activation and a cure period of 5-15 seconds. It allows you to make 3D printed figures, architectural models, jewelry, tiny automobiles, and motorcycles, among other things. It allows for quick, high-precision printing. It’s been designed to work with Photon and Photon S 3D printers from 3D Systems.
Highlight
- Top-Choice for Entry-Level Users: Following the classic formula, Anycubic Standard Colored UV Resin is well integrated and in balance with the performance on printing precision, hardness, fluidity, etc.
- High Precision, Fast Printing: This resin ensures the strength of molded parts and not excessive shrinkage, but also improves print speed, shortens the curing time and enhances the printing efficiency of LCD machines as much as possible.
- Strong Adhesion During Printing, Easy to Detach After Forming: Not only success rate of printing and precision is high, but also the resin release force and adhesion are minimized, so that the model attached to the forming platform can be easily shoveled up. And low viscosity facilitates the cleaning of machines and models.
- Stable Performance, Wide Compatibility: Stable and easy to store under different climatic conditions, it overcomes the shortcomings of other resins that are easy to be softened by moisture and corroded by the environment.; Sensitive to 365-410 nm UV wavelength, especially, better results in use with Anycubic 3D resin printers.
- User Guide: To ensure its stable performance, please shake the resin well before use and keep sealed and away from light after use; To ensure your safety, please wear gloves before use to avoid direct contact with the skin and keep the room ventilated.
Parameters of the resin:
- 1.05-1.25g/cm3 density
- 150-200 cP or maps viscosity
- Shrinkage during molding: 3.72-4.24 percent
- The hardness of the surface: 84 HD
- 50-70 MPa flexural strength
- 36-52 MPa tensile strength
- 1,200-1,600 MPa Flexural Modulus
- 11-20% elongation at the break
- 1-year shelf life
Specifications for color:
- Clear is the name of the color.
- Color attribute: Translucent
- Translucent Net is a color characteristic. 1-liter weight
Instructions for Use
(1) Before use:
Shake the liquid resin before use;Clean the resin tank and the molding platform to keep the bottom of the resin tank in light transmission.
(2) When using:
Unscrew the cap and add it to the resin tank according to the equipment requirements;Select the correct print parameters and settings for printing.
(3) After use:
After printing, please use the matching tools for post-processing, including blade, diagonal pliers,tweezers,containers,gloves;ethanol(≥95%),lactate or isopropyl alcohol cleaning solution;
(4) Post-processing steps:
A. Remove the printed model from the molding platform with a blade;
B. Submerge the model in the cleaning solution, rinsed or ultrasonically washed, then taken out and drained; ANYCUBlC Wash and Cure machines are suggested to ensure better effect.
C.Proper processing, such as removing support, polishing, coloring, etc.
Precautions
- The ideal condition for storing uncured resin is a cool, dark place at room temperature and protect from light to avoid high temperature or sunlight.
- Suggested operating temperature is 18-35°C, and a low temperature may affect the printing effect, thus, the resin can be properly preheated before use (not more than 60°C).
- If the resin pigment settles, it can be used after stirring or shaking.
- In order to ensure the performance of the resin, please take out the model in time after cleaning to avoid the model soaking in water for a long time.
- To ensure the mechanical properties of the model, please perform post-curing in time after cleaning and drying.
- To ensure the ideal performance of the curable material, it is necessary to control the intensity and time of the light source after curing.Therefore, the following steps are recommended:
(1) The intensity of mercury lamp or Led light source is 5-10mW/m?, and the duration is no more than 1 hour (self-regulation);
(2)The exposure time in the sun (summer) is around 1 hour;
(3) Proximity or long-term exposure under strong light sources such as high-power high-pressure mercury
lamps is prohibited.
(4) lt is recommended to print in a dark room or be covered with a lid while printing as resin is a photosensitive
material.
