Features of IFUN Denture Base Resin(3166 )
Highly biocompatible safe to allergic patients.
It has high biocompatibility with oral tissue. Ensure a healthy oral environment and a high degree of comfort.
Excellent mechanical properties.
The denture base printed with our 3166 resin are durable and resist fracture
Excellent mechanical properties.
- Post Processing Steps
-
1- Washing
– After the printing is completed, wash the part as attached to the building plate with alcohol (>%95) for 3 minutes.
– Make sure that alcohol covers the part entirely when washing.
– Since the Denture resin is biocompatible never wash it with the alcohol used for other resins before.
– Use a brush to remove uncured resin if needed.
– Do not over-wash, it may cause deterioration in dimensions of the part.2- Drying
– Use air-compressor to dry the washed part.
– Make sure that the part is dry and uncured resin is cleaned up completely.
– If still uncured resin left on the part, wash it with fresh alcohol and dry again.3- Part Removal
– Remove the printed part from the building plate using a scraping tool.
– Be very careful not to damage the model.4- Post Curing
– UV post-curing for 5 minutes
–
After the post curing, supports should be removed from the model
cautiously and then desired sandblasting and polishing can be done
project | Content | Data value | Testing method |
Physical and
chemical properties (before curing) |
color | Pink | |
Viscosity | 450-750cps(25℃) | ASTM D1084-1997 | |
Density | 1.05-1.15 | ASM D1875-69(1980) | |
Physical and
chemical properties (after curing) |
Curing depth | 500~700μm | |
Shrinkage | <1% | ||
Hardness | 70~80D | ASTM D2240-05(2010)
|
|
bending strength | >3kg | . |
