Product main technical parameters:
Nominal resistance: R25 (25°C): (commonly used) 1.5K, 2K, 5K, 10K, 20K, 30K, 47K, 50K, 100K, 200K, 500K, etc.
B arium resistance accuracy: ±1%, ±2%, ±3%
B value R25/50: (usually) 3435K, 3600K, 3950K, 3990K, 4100K, 4200K, etc.
B accuracy: ±1%
Operating temperature range: -40°C~+300°C
Dissipation power factor: ≥5 mW/°C (in static air)
Large rated power: 45mW
Thermal time constant: ≤7S (in static air)
Resistance temperature coefficient: -2~-5%/°C
Recommended parameters: R25°C=100K B25/50=3950K±1%
● Product features:
High sensitivity and rapid response
Compact and easy to install
Wide temperature range, good stability and high reliability
Can provide different R, B value products, strong interchangeability, high precision
