Bambu Lab P2S Combo
The Bambu Lab P2S Combo is a high-performance FDM 3D printing system engineered for precision, automation, and advanced multi-material production. Combining the P2S printer with the AMS 2 Pro, this configuration delivers intelligent filament management, high-speed extrusion, and controlled environmental printing for professional-grade results.
Core Printing Technology
- Printing Method: Fused Deposition Modeling (FDM)
- Build Volume: 256 × 256 × 256 mm
- Chassis Construction: Plastic and steel frame with glass enclosure
- Fully Enclosed Chamber: Optimized for stable thermal conditions and engineering-grade materials
Extrusion & Toolhead System
- Extruder Type: PMSM high-precision permanent magnet synchronous motor
- Maximum Extrusion Force: 8.5 kg
- Sampling Rate: 20 kHz real-time resistance monitoring
- Nozzle Material: Hardened steel
- Max Nozzle Temperature: 300°C
- Nozzle Sizes Supported: 0.2 / 0.4 / 0.6 / 0.8 mm
- Quick-Swap Hotend: One-clip mechanism for rapid nozzle replacement
- Filament Cutter: Integrated automatic cutting system
Intelligent Calibration & Print Accuracy
- Flow Dynamics Calibration: Eddy current pressure sensor with active compensation
- Auto Flowrate Adjustment: Real-time extrusion tuning across layers
- AI Error Detection: Computer vision-based monitoring (spaghetti, clogging, failure detection)
- Processing Unit: Integrated NPU (2 TOPS) for real-time analysis
Cooling & Thermal Management
- Adaptive Airflow System: External cold-air intake with internal heat retention
- Chamber Capability: Up to 50°C passive chamber temperature
- Air Filtration: Carbon filter for enclosed printing environment
- Heatbed Temperature Range: 35°C – 110°C
- Build Plate: Flexible steel plate
AMS 2 Pro – Multi-Material System
- Multi-Color Printing: Supports automated filament switching
- Filament Slots: Expandable up to 20 colors (with multiple AMS units)
- Feeding Speed: 60% faster filament switching
- Filament Drying System: Active venting drying (30% faster than sealed systems)
- Humidity Control: Airtight storage with automated venting
- Connectivity: 6-pin cable integration with printer
Connectivity & Monitoring
- Display: 5-inch touchscreen with 2nd-generation UI
- Camera: 1080P high-frame-rate monitoring with timelapse support
- Lighting: Integrated high-intensity LED system
- Wireless: Dual-band Wi-Fi for remote control and monitoring
Material Compatibility
- Filament Diameter: 1.75 mm
- Supported Materials: PLA, PETG, TPU, and engineering-grade filaments
- Fiber-Reinforced Materials: Supported via hardened extrusion system
- Drying Integration: AMS maintains optimal filament condition during storage and printing
Physical Specifications
- Printer Dimensions: 392 × 406 × 478 mm
- Recommended Space: 500 × 500 × 950 mm
- Net Weight (Combo): 16.4 kg
- Gross Weight (Combo): 21.33 kg
System Features
- Fully enclosed high-stability printing environment
- Real-time AI-driven print monitoring and failure detection
- High-speed, high-force extrusion with precision control
- Multi-material and multi-color printing via AMS 2 Pro
- Integrated filament drying and humidity management
- Advanced airflow and cooling architecture
- Remote monitoring with high-resolution live view
Compliance & Engineering
- Cybersecurity compliant with EU RED Article 3.3(d)(e)
- Conforms to ETSI EN 303 645 V2.1.1:2020 standards
