Features of Dental mould resin(3160)
It is an excellent resin material for 3D printing dental moulds
High accuracy
The 3160 resin printed tooth mold has a clear edge, which fully meets the requirements of dental restoration accuracy.
Suitable for orthodontic dental models
3160
resin has high strength and high temperature resistance; it is easy to
remove after lamination and will not stick to the model, so it can be
well used for orthodontic lamination.
Suitable for dental implants
3160
resin has high molding precision. With the LCD printer, the molding
accuracy is controlled at about 35μm, which is higher than the industry
standard. 90% of the surface accuracy should be controlled within 100μm,
and the accuracy of the edges and occlusion points of the model is
within 50μm.
Customized production
With
LCD 3D printer, it takes only 40 minutes to print 8 models, about 5
minutes per piece. 1KG of resin material material can print 100 pieces
of dental molds.
You can download the parameter here.
| Content | Data value | Testing method |
| Viscosity | 380-400cps(25℃) | ASTM D1084-1997 |
| Density | 1.2 | ASM D1875-69(1980) |
| Shrinkage | ＜0.5% | Capillary method |
| Hardness | >82D | ASTM D2240-05(2010) |
| Deformation temperature | 120℃ | ASTM D1929-1996 |
| Bending strength | >60 MPa | ASTM D1781 |
